45° Bevel Tube Laser Cutting Machine 3000-4000W

Product Description

< 3D Five-axis Cutting Head, 45° Bevel >

Self-developed by HSG Laser

Take control of laser focus thanks to its fully automated servo motor

Laser path reshaping technology

Swingable head outfitted with the function of collision prevention

Modular structure in favor of repair or maintenance

< HSG-X Bus CNC System >
* Bus refers to data transmission mode via on-site bus control system.

< Double Digital Chucks >
The chucks are outfitted with pressure feedback system to adjust cutting pressure based on tube size and thickness.They are also featured by auto recognition of different tubes and real-time warning with no or less manual intervention.

Closed-loop control

Detect real-life state of clamping claws

Access to tube data easily

Self-adaptive adjustment of clamping force

Our Advantages

Space Leapfrog and Flying Cutting

--The technology helps to minimize the moving path of cutting head by omitting repeated lift and fall, therefore, cutting speed is improved beyond doubt.

--With three-axis linear interpolation, TPS performs well while cutting into small densely-distributed graphics.

Labor-saving Configurations

Standard Tube Automatic Loading Device (Optional)
Tube to be cut is conveyed to check-waiting area for length measuring and cut sequencing. Support frame is used for supporting tubes to ensure cutting stability and precision.

Unloading Device (Default)
Unloading height is manually adjusted when unloading different types of tubes. Additionally follow-up unloading device is also optional.

Specification

Applications
HSG Fiber Laser Cutting Machines are widely used in Manufacture Billboard, Signs, Advertising, Signage, Metal Letters, Kitchen Ware, Advertising Letters, Sheet Metal Processing, Metals Components and Parts, Ironware, Chassis, Racks & Cabinets Processing, Metal Crafts, Metal Art Ware, Elevator Panel Cutting, Hardware, Auto Parts, Glasses Frame, Electronic Parts Nameplates, etc.

Technical Parameter

Sample Display

Certifications

Visit & Exhibition

Packaging & Shipping

1-Our high-standard package include aluminum foil, metal framework, fumigation wooden case, anti-rust oil+oilpaper, moisture-barrier bag, waterproof plastic film and filling foam, in order to satisfy ocean shipping criteria. 2-We will ensure they can be delivered to customers ASAP. without damage. 3-We also support a variety of transportation methods.
